實驗型模面熱切雙螺桿造粒線是一種專為實驗室研發、小批量生產及材料改性設計的高效造粒設備,廣泛應用于高分子材料加工領域。其核心優勢在于通過雙螺桿的強混合能力與模面熱切技術,實現物料的高效塑化、均質化及精密造粒。
The experimental model surface hot cutting twin-screw granulation line is a high-efficiency granulation device specifically designed for laboratory R&D, small-scale production, and material modification. It is widely used in the processing of polymer materials. Its core advantage lies in its ability to achieve efficient plasticization, homogenization, and precise granulation through the strong mixing capability of twin screws and the model surface hot cutting technology
聚合物料混合、混煉擠出造粒Polymer material mixing, extrusion and granulation
復合材料的共混改性與反應擠出Blending modification and extrusion of composite materials
高分子合金高效混煉 Efficient mixing of polymer alloys
聚合物填充增強改性 Polymer filling, reinforcement modification
物料脫水、脫揮與排氣 Material dehydration, devolatilization, and exhaust
小批量生產Small batch production
型號Model No. | XH-433-25 | XH-433-35 |
控制系統 Control system | PLC控制PLC control | |
產量(kg) Capacity | 約1-10kg/h根據工藝配方 1-10kg/h(decide by formula ) | 約30kg/h根據工藝配方 About 30kg/h(decide by formula ) |
喂料機 Feeder | 雙螺桿定量喂料或指定 Twin screw quantitative feeding or customize | |
| 螺桿直徑 Screw diameter | 21.7mm或指定(or customized | 35mm或指定(or customized) |
長徑比 L/D | 40:1 | 40:1/48:1 |
螺桿轉速rpm Screw speed | 0-300rpm | 0-300rpm |
主電機 Motor | 4kW | 18kW |
冷卻裝置 Cooling device | 風冷(可選配) water cooling (optional) | |
| 切粒方式 Cutting device | 熱切 hot cutting | |
換網器 Switching device | 手動換網器 Manual screen changer | |
總功率 Total power | 12kW | 30kW |
體積(mm)(W×D×H) Volume | 4000*550*1600mm | 6800×960×1940mm |
重量(kg) Weight | 約600kg | 約 1900kg |
電 源 Power Supply | 3∮,AC380 | |
